Easy to install, compatible with most vehicles.

• Easy to install and designed to be compatible with different vehicles
• Quick installation by use of quick connect “T-tap” connectors
• Connectors allow for quick replacement/removal of the ignition security system
• Allows the vehicle to stay running when the key is removed from the ignition switch
• Brake pedal and shift lever movement disables the ignition security system and stops the engine (sounds horn if connected)
• Over-ride simply deactivates by turning the key to the run position and depressing the brake
• Automatic low voltage detection will activate the horn to provide notification of vehicle problems
• The additional universal output provides normally open or normally closed contact for starter disable, gun lock disables, camera record, etc.
• Includes illuminated remote switch
• Optional horn or siren alarm
• Order Number
• 2007 Ignition Security System (I.S.S.)

• Input Voltage Range: 10-16 VDC

Current Draw

• Heavy Duty: 8 outputs, 130 Amp total
• Standard: 4-10 Amp output

Dimensions

• Heavy Duty: 6" (15 cm) L x 3.5" (8.9 cm) H x 1.5" (3.8 cm) D
• Standard: 6" (15 cm) L x 3.4" (8.6 cm) H x 0.8" (2 cm) D
