Havis Standard White K9 Transport System for 2017-2021 Ford F-Series

by Havis
SKU K9-F23-1
  • Next generation front slider door with full door range of motion left to right and improved sliders to eliminate rattle
  • Smooth edges and tight gaps to prevent injury, catch and chew points
  • For 2017-2021 Ford F-250, 350, 450 crew cab pickup, F-450 and 550 crew cab /cab chassis, 2015-2021 Ford F-150 and F-150 Special Service vehicle (SSV) crew cab pickup
  • Kit housing with one front sliding door, aluminum door panels and fold-down interior window guards
  • Fabricated from Heavy-duty aluminum for long-lasting durability
  • Durable white powder coat finish on main components
  • Black powder coat finish on center sliding door and window guards
  • Easy to install and clean
  • Designed to maximize driver seat travel without compromising K9 entry
  • Mounts to OEM mounting points. (no drilling required)
  • Window guards include bolt on flat panels that can be removed for optional 10" emergency exhaust fan mounting
  • Optional 10" fan and mount kit (use p/n: K9-A-104) can mount on driver or passenger side
  • Includes adaptors and hose to connect from OEM ductwork under seats. hose connects to vents on K9 compartment front wall
  • Upper guard on rear wall folds down to allow easy access and cleaning
  • Lower rear wall includes locking fold down door to access vehicle jack, OEM optional inverter and access for cleaning
  • To relocate mount location for jack kit and optional inverter, use K9-A-114
  • K9 kit window guards include a .281" x 1.75" slotted hole pattern to minimize the possibility of fingers accidentally being put into the K9 compartment
  • Optional 10" fan and mount kit for window guard mounting (# K9-A-104 fan option sold separately)
  • Purchasing OEM optional running boards is recommended to aid in K9 entry
  • Kit inside dimensions: 28" deep by 65" wide by 43.5" high
  • Side entry openings: 25.5" wide x 37" high
  • Front wall sliding door opening: 14" wide x 30" high
  • K9 compartment floor to ground: 29.375"
  • Storage space between rear K9 wall and cab wall = 6 inches long x width of cab
  • Hot-N-Pop system K9-A-201 not available for retail truck with rotary shifter on OEM console
  • Only the heat alarm system K9-A-203 is available for retail truck with rotary shifter
  • 12" fan not recommended
  • Does not accept the K9-A-101 option
  • Gross Weight:250.00 lbs

Abbreviated Product Description:

K9, INSERT, F250, 17-21, F150, 15-21,

Download any of the following documents for additional product information:
