- C-PM-122 printer mount
- Overall measurements = 12.89" high x 9" wide x 38" long (including forward trim panel)
- See side view drawing min/max mounting depth allowed for control heads and/or options
- OEM tunnel plate must be removed
- If using console with a vertical gun rack between seats, a partition with gun alcove is recommended. there is 9.5" from end of console to Pro-gard a partition gun alcove. dual weapons mount not recommended because of lack of space.
- Works with column shifter and OEM full length center console (OEM console must be removed, but the dash will have uncovered areas on the sides) dash parts to fill space can be ordered from Ford. rear OEM ductwork must also be removed and blocked off.
- Does not work on higher trim levels with OEM full length center console that includes mounted shifter (OEM console cannot be removed)
- Does not work with 4 x 4 floor shifter (works with dash mounted 4 x 4 selector switch)
- Does not work with OEM manual transmission floor shifter
- Now ships UPS
- 3.3"W section now comes unpopulated
- Customize to your specific needs
- Includes equipment brackets and filler plates to enclose area
- See Havis 3.3" wide console accessories for options
- 3.3"W section now comes unpopulated
- Customize to your specific needs
- Includes equipment brackets and filler plates to enclose area
- See Havis 3.3" wide console accessories for options
-
Gross Weight: �47.00 lbs
Abbreviated Product Description:
CON, CS, VSW, WIDE, 30TMS, 0DG, HC, F150, F250, 17-21, SP,
